Ludwig Schneider Pt100 Transition-Sleeve Sensor with Handle – Class A, −50 to +200 °C, 150 mm, Ø 3 mm, 5 m Cable

The Ludwig Schneider Pt100 Transition-Sleeve Sensor with handle offers precision temperature measurement with enhanced versatility. Featuring Class A accuracy and a temperature range from −50 °C to +200 °C, this sensor combines a 150 mm long, Ø 3 mm stainless steel probe with a transition sleeve design—ideal for installations requiring a protective sheath or compatibility with specific fittings. The attached 5 m cable ensures flexibility for connection to control systems or remote monitoring setups.

Key Features:

• Brand: Ludwig Schneider
• Sensor Type: Pt100 (Platinum Resistance Thermometer), Class A accuracy
• Temperature Range: −50 °C to +200 °C
• Probe Diameter: Ø 3 mm
• Probe Length: 150 mm
• Cable Length: 5 m
• Design: Transition sleeve with ergonomic handle—ideal for retrofitting or insertion into thermowells
• Applications: Laboratory setups, process fittings, calibration, and installations requiring sleeve-based adaptation

With its combination of accuracy, protective sleeve compatibility, and extended cable reach, this sensor is well-suited for demanding lab and process environments requiring adaptability and precision.
